Mr12volt Porsche CarPlay Android Auto w/ DSP + MOST PCM 3.0 MM with integrated mic (NEW VERSION)


Mr12Volt PCM 3.0 MM on the following Porsches:
911 2009 – 2011
Cayenne 2009
Boxster/Cayman 2009-2012


SKU: N/A Category:

Save with product bundles

Discounts will be applied in cart

Original price was: $15.00.Current price is: $0.00.
Original price was: $10.00.Current price is: $0.00.
Original price was: $534.99.Current price is: $509.99.
For 3 items

MOST Bus CarPlay & Android Auto Interface

Model No: P2000-PCM30MM
The brand new Mr12Volt P2000 MM series has just gotten better now with OEM microphone support.

Compatible with PCM 3.0 on the following Porsches:

911                              2009 – 2011
Cayenne                    2009
Boxster/Cayman     2009-2012

Highlight Features:

  • Supports OEM microphone
  • Runs on MOST BUS with High-End sound quality
  • Wireless & Wired Apple CarPlay, Google Android Auto
  • Wireless MirrorLink
  • Bluetooth Hands free & Audio Streaming
  • USB Video & Music Playback
  • Reverse/Front/Left/Right camera Input
  • Supports Apple Lossless music streaming
  • Highly Customizable 15 bar DSP Equalizer

How it works

  • Mr12volt is selected through TV features of PCM
  • No coding or Factory TV module is needed, once Mr12volt CarPlay module is installed successfully, the “TV” icon will appear on the PCM home menu right away.
  • Supports aftermarket cameras up to AHD720

P2000 supported multimedia type (High performance video and audio codec)

  • Decoding H.264 (Baseline and Main High Profile, Level 1-4.2)  30fps @1080p
  • Decoding VC-1 (Simple Main Profile, low, medium and high levels. Advanced Profile, levels 0-3) 30fps @1080p
  • Decoding MPEG1/2/4 (Simple Profile, levels 0-6. Main Profile, low, medium andhigh levels. ASP, levels 0-5) 30fps @1080p
  • Decoding Real-Video 8/9/10 30fps @1080p
  • Decoding VP6/7/8 (VP6.0/1/2, VP7 version 0-3, VP8 version 2(WebM)) 30fps @1080p
  • Decoding DivX (DivX3/4/5/6) 30fps @1080p
  • Decoding H.263 (Profile 0, levels 10-70.) 30fps @720×576
  • JPEG codec (Baseline interleaved) 8176×8176
  • Support *.mkv, *.mp4, *.avi, *.wmv, *.rmvb, *.rm, *.mpg, *.mpeg, *.ts, *.dat, *.asf, *.flv, *.vob, and so on file format
  • Multi Format Audio CODEC (MP3, WMA, AAC, AC3, DTS, OGG, FLAC, APE, AMR, and so on)

Related Topics:

How to mirror to P2000 from phone

Additional Technical Data:

  • Operating Temperature: -20 – +80 degree centigrade
  • DAC resolution: 18Bit
  • MP3 kbit: 8 – 384kbit
  • Voltage: 10 – 14.6V DC
  • Operation Current: 450mA (700mA when charging mobile phone)
  • S/N ratio: 95dB
  • Total Harmonic Distortion: 0.1%
  • Frequency Response: 20Hz – 20KHz
